WS10.0CI

10HP 300L Three-Phase Workshop Air Compressor 400V

Ultimate Air Power - Massive 3-phase 10HP motor with a huge 1187 L/min (42 CFM) pump displacement delivers industry-leading performance for the most demanding air applications.
Huge Output at Working Pressure – 893 L/min FAD at 90 PSI for continuous operation of multiple high-demand air tools.
Massive 300L Air Tank – Huge reserve for extended run times with fewer refills.
Slow-Revving, Heavy-Duty Pump – 4-cylinder cast iron twin-stage design runs at just 770 rpm for
cooler operation, greater efficiency, and maximum pump life.
Two-Stage Pump Design – Increased efficiency at working pressure, reduced power consumption,
and drier air output for better tool performance.
Smooth & Stable Operation – Separate pump and motor mounting plate with rubber foot kit to
reduce vibration and simplify maintenance.
3ph 400V 20A Power Supply Requirements

Motor: 7.5kW / 10HP 3 Phase 400V IE2

Receiver Size: 300L

Pump Displacement 1187L/min, 42cfm

Maximum Working Pressure: 10bar / 145PSI

Attribute name	Attribute value
Dimensions	160 x 53 x 113cm (L x W x H)
Weight	311kg
Pump Type	V' 4 Cylinder Cast Iron Twin Stage
Motor:	7.5kW / 10HP 3 Phase 400V IE2
Receiver Size:	300L
Power Supply Requirement	400V 3 Phase 20A
Pump Displacement	1187L/min, 42cfm
FAD @ Working Pressure	893L/min
Maximum Working Pressure:	10bar / 145PSI
Pump Speed:	770 RPM
Duty Cycle	60%
Drive Belt Specification:	B1956
Receiver End Port Thread Size:	G 1/2"
Sound Pressure Level	80dBA
