AC17P/1

BELT DRIVE COMPRESSOR
  • Honda GX160 genuine 5.5HP - 4 stroke, recoil start
  • Belt driven 2 cylinder pump
  • Idle control reduces pump and motor RPM when tank pressure reaches set cutout
  • Pressure regulator with quick coupler air outlet
  • Direct air outlet on tank end with ball valve
  • Robust and portable with solid rubber wheels and heavy duty roll bar protection
  • 100% Italian
  • 24 month warranty
Enquire Now Download Brochure

Product Highlights

Picture for category Motor Size: Motor Size: 5.5hp
Picture for category Air Delivery: Free Air Delivery: 11.9cfm, 337L/min
Best Displacement: 14.9cfm, 421L/min
Picture for category Tank capacity: Tank capacity: 50 Litres
Picture for category Maximum Pressure: Maximum Pressure: 145psi

Technical specifications

Attribute nameAttribute value
Motor Size:5.5hp
Best Displacement:14.9cfm, 421L/min
Free Air Delivery:11.9cfm, 337L/min
Maximum Pressure:145psi
Cylinders:2
Pump Speed:1190rpm
Tank capacity:50 Litres
Dimensions96 x 47 x 76cm
Weight70kg
